Drivers (LuxDrive)

ProductTopologyIn / OutputInput VoltageOutput CurrentDimming Detail
QuadPuck 4016BuckDC / DC12 to 24 VDC1000 to 2100 mAPWMLink
QuadBlock F017BuckDC / DC12 to 24 VDC1000 to 2100 mAPWMLink
PowerPuck 2008BBuckDC / DC5 to 32 VDC350 to 1000 mANoneLink
MiniPuck F004BuckDC / DC6.5 to 30 VDC 350 to 700 mAPWMLink
MicroPuck 2009BuckDC / DC0.8 to 3 VDC350 to 600 mANoneLink
FlexBlock A011Buck-Boost, BoostDC / DC10 to 32 VDC350 to 700 mA0 - 10 VLink
DynaOhm 4006LinearDC / DC(2.6V + Vf) to 52 VDC20 to 30 mANoneLink
BuckToot 7027BuckDC / DC5 to 28 VDC350 mANoneLink
BuckPuck 302xDBuckDC / DC5 to 32 VDC350 to 1000 mA0 - 10 VLink
BuckPuck 302xABuckAC / DC7 to 24 VRMS350 to 1000 mA0 - 10 VLink
BuckBullet 7006BuckAC / DC8 to 24 VRMS350 to 800 mANoneLink
BuckBlock A009BuckDC / DC10 to 32 VDC1000 to 2100 mA0 - 10 VLink
BoostPuck 4015BoostDC / DC5 to 28 VDC350 mA0 - 10 VLink

* All specifications are subject to change without prior notification.

Light Engines

PRODUCT LED TYPE SHAPE LED COUNTLUMENSField CutCut Interval DETAILS
DuoStrip I033
Nichia 757Strip - 12 in48up to 880Yes3 InLink
DynaSqr G025Nichia 757Square 1 in3up to 136NoNoneLink
Elara Strip II 7011NichiaStrip - 11.5 in9up to 450Yes4 InLink
LUXStrip II 9008Luxeon RebelStrip - 12 in6up to 1080Yes2 InLink
LUXStrip II A006Cree XP-E & XP-GStrip - 12 in6up to 1270Yes2 InLink

* All specifications are subject to change without prior notification.

Light Modules

PRODUCT LED TYPE SHAPE LED COUNT LUMENS DETAILS
Endor Star 7007 & 7040Luxeon RebelStar1 or 365 to 540Link
Indus Star A007 & A008Cree X-PE2 & X-PG2Star1 or 3105 to 144Link

* All specifications subject to change without prior notification.

Fixtures & Lamps

PRODUCTTYPE LUMENS DIMMING USAGE DETAIL
LVL 2Luminaire450 to 600YesDryLink
LVL 4Luminaire850 to 1000YesWetLink

* All specifications are subject to change without prior notification.

Controls

PART NUMBERInterface DIMMING CONNECTIONDETAILS
LVDCRotary & Slider0 to 10 V2 Wire LeadLink
