Indus Star A007 & A008 – Cree LED Light Module

Product Description

The Indus Star combines high brightness with ease of integration into fixtures and OEM applications. The LUXdrive™ Indus Star features a wide range of Cree XLamp emitters in both 1-up and 3-up designs on a 20mm star board. Inherent electrical isolation means thermal interface materials are not required to be electrically insulative. LEDdynamics strives to use the highest flux bins that are most readily available, please contact us if you require a specific bin.

Download

Literature

Data Sheet – Indus A007 & A008 Cree LED Light Modules

Features

Made in America design and quality
Customization of specifications available
Available in range of colors and white
Beam sculpting optics available

Applications

General Illumination
Display Case Lighting
Sign Lighting
Flashlights

White 1-Up Product Selection Guide

Star Design	Cree LED	Part Number	CCT	CRI	Voltage (V_f)	Lumens @350mA
1-Up Cree XLamp XP Package (3.45mm) on 20mm Star	XP-L2	A007-CL20830V2	3000K	80	2.79¹	400¹
		A007-CL20840V3	4000K	80		420¹
		A007-CL20750V4	5000K	80		440¹
		A007-CL20765V5	6500K	80		460¹
	XP-G3	A007-CG30827R4	2700K	80	2.70	119
		A007-CG30830R5	3000K	80		139
		A007-CG30840S2	4000K	80		148
		A007-CG30750S3	5000K	70		156
		A007-CG30765S4	6500K	70		164
	XP-G2 HE	A007-CG2H830R5	3000K	80	2.70	139
		A007-CG2H840S3	4000K	80		156
		A007-CG2H750S3	5000K	70		156
		A007-CG2H765S4	6500K	70		164
	XP-E2	A007-E2827-Q2	2700K	80	2.84	87
		A007-E2830-Q3	3000K	80		93
		A007-E2740-Q4	4000K	70		114
		A007-E2750-Q4	5000K	70		156

Values specified @350mA, T_j 85°C – for more specs, visit emitter data sheet: XP-L2, XP-G3, XP-G2 HE, XP-E2
Cree XP-L2 is tested @ 1050mA, Tj 85°C
All specifications are subject to change without prior notification.

White 3-Up Product Selection Guide

Star Design	Cree LED	Part Number	CCT	CRI	Voltage (V_f)	Lumens @350mA
3-Up Cree XLamp XP Package (3.45mm) on 20mm Star	XP-L2	A008-CL20830V2	3000K	80	8.37¹	1200¹
		A008-CL20840V3	4000K	80		1260¹
		A008-CL20750V4	5000K	80		1320¹
		A008-CL20765V5	6500K	80		1380¹
	XP-G3	A008-CG30827R4	2700K	80	8.10	357
		A008-CG30830R5	3000K	80		414
		A008-CG30840S2	4000K	80		444
		A008-CG30750S3	5000K	70		468
		A008-CG30765S4	6500K	70		492
	XP-G2 HE	A008-CG2H830R5	3000K	80	8.10	417
		A008-CG2H840S3	4000K	80		468
		A008-CG2H750S3	5000K	70		468
		A008-CG2H765S4	6500K	70		492
	XP-E2	A008-E2827-Q2	2700K	80	8.52	261
		A008-E2830-Q3	3000K	80		279
		A008-E2740-Q4	4000K	70		342
		A008-E2750-Q4	5000K	70		468

Values specified @350mA, T_j 85°C – for more specs, visit emitter data sheet: XP-L2, XP-G3, XP-G2 HE, XP-E2
Cree XP-L2 is tested @ 1050mA, Tj 85°C
All specifications are subject to change without prior notification.

Color Product Selection Guide

Star Design	Cree LED	Part Number	Color	Wavelength (NM)	Voltage (V_f)	Lumens @350mA
1-Up	XP-G3	A007-CG30PHR32	Photo Red	645	1.99	500²
	XP-G3	A007-CG30ROYF4	Royal Blue	451	2.79	730²
	XP-E2	A007-CE20AMBP4	Amber	585-595	2.18	80.6
		A007-CE2BLUM3	Blue	465-485	2.85	45.7
		A007-CE20FAR27	Far Red	720-740	1.85	375²
		A007-CE20GRNR3	Green	520-535	2.70	122
		A007-CE20PCAQ5	PC Amber	~	2.94	107
		A007-CE2PHR30	Photo Red	650-670	2.05	450²
		A007-CE20REDP3	Red	620-630	2.18	73.9
		A007-CE20RDOQ5	Red-Orange	610-620	2.18	107
		A007-CE20ROY37	Royal Blue	450-465	2.96	450²
3-Up	XP-G3	A008-CG30PHR32	Photo Red	645	5.97	1500²
	XP-G3	A008-CG30ROYF4	Royal Blue	451	8.37	2190²
	XP-E2	A008-CE20AMBP4	Amber	585-595	6.54	242
		A008-CE2BLUM3	Blue	465-485	8.55	137
		A008-CE20FAR27	Far Red	720-740	5.55	1125²
		A008-CE20GRNR3	Green	520-535	8.1	366
		A008-CE20PCAQ5	PC Amber	~	8.82	321
		A008-CE2PHR30	Photo Red	650-670	6.15	1350²
		A008-CE20REDP3	Red	620-630	6.54	222
		A008-CE20RDOQ5	Red-Orange	610-620	6.54	321
		A008-CE20ROY37	Royal Blue	450-465	8.79	1350²
		A008-CE20RGB00	Red/Green/Blue	see emitter values	see below³	see emitter values

Values specified @350mA, T_j 25°C – for more specs, visit emitter data sheet: XP-L2, XP-G3, XP-G2 HE, XP-E2
Photo Red, Far Red, and Royal Blue are binned by radiometric power. All other colors are binned by luminous flux.
RGB LED boards are built without the 0 ohm jumpers connecting the LEDs in series, each LED is individually driven so that you can RGB color mix.
All specifications are subject to change without prior notification.

Specific Maximum Ratings

LED Series	DC Current (mA)	Typ. Viewing Angle	Thermal Resistance (°C/W)*
			1-up	3-up
Cree XP-L2	3000	125°	1.6°	1.2°
Cree XP-G3 - Whites	2000	125°	4°	2°
Cree XP-G3 - Photo Red	1500	125°	3.5°	2°
Cree XP-G3 - Royal Blue	2000	130°	3°	1.83°
Cree XP-G2 HE	2000	125°	4°	2°
Cree XP-E2 - Whites	1500	110°	6.8°	2.93°
Cree XP-E2 - Amber	1500	130°	8.5°	3.5°
Cree XP-E2 - Blue, Royal Blue	1200	135°	6.7°	2.90°
Cree XP-E2 - Far Red	1500	140°	7.5°	3.17°
Cree XP-E2 - Green	1500	135°	10°	2°
Cree XP-E2 - PC Amber	1500	105°	6.5°	2.83°
Cree XP-E2 - Red, Photo Red, Red-Orange	1500	130°	7.5°	3.17°

*LED junction to bottom of starboard (MCPCB), measured in °C/W

Accessory Ordering Detail

Type	Category	Part Number	Description	LED Number	Beam Angle	Count
XP-G2	Optics	CO-10003	Plain Tight	1	12^o	~
		CO-10138	Frosted Narrow	1	14^o	~
		CO-10003-15	Ripple Medium	1	29^o	~
		CO-10139	Frosted Medium	1	21^o	~
		CO-10003-25	Ripple Wide	1	41^o	~
		CO-10140	Frosted Wide	1	31^o	~
		CO-10003-L25	Elliptical	1	44 x 12^o	~
		CO-10734	Universal Holder	1	~	~
XP-E2	Optics	CO-10193	Plain Tight	3	8^o	~
		CO-10194	Frosted Narrow	3	10^o	~
		CO-10208	Ripple Medium	3	28^o	~
		CO-10195	Frosted Medium	3	43^o	~
		CO-10209	Ripple Wide	3	31^o	~
		CO-10196	Frosted Wide	3	47 x 8^o	~
		CO-10197	Elliptical	3	~	~
		CO-10736	Universal Holder	3	~	~
XP-E2 & XP-G2	Optics	CO-10507	Spot Base Module	3	16^o	~
		CO-10511	Frosted Spot Base Module	3	22^o	~
		CO-10508	Medium Base Module	3	26^o	~
		CO-10509	Wide Frosted Base Module	3	37^o	~
		CO-10510	Oval Base Module	3	43 x 16^o	~
General	Thermal	A001-010H	Thermal Adhesive Tape	~		10
General	Thermal	A001-150H	Thermal Adhesive Tape	~		150

* All specifications are subject to change without prior notification.
